spring boot +springboot集成es7.9.1+canal同步到es

• 前言
• • 参考资料来源
  • rocketmq
  • elasticsearch
  • canal
  • 消费MQ订阅的canal信息，进行elasticsearch的同步以及搜索

未经许可，请勿转载。

前言

1. 其实大部分的代码是来源于参考资料来源 的主要代码实现，我只是在他的基础上增加自定义注解，自定义分词器等。需要看详细源码的可以去看主要代码实现，结合我的来使用。
2. 有人会问为什么需要自定义注解，因为elasticsearch7.6 索引将去除type 没有类型的概念了。所以我自己自定义数据类型，有需要的可以自己拓展自己需要的类型。
3. 我这里主要写的是代码实现，没有涉及到中间件的搭建，因为真的没有时间，哈哈。

参考资料来源

主要实现代码：https://gitee.com/gz-yami/mall4cloud?_from=gitee_search
自定义注解：https://cloud.tencent.com/developer/article/1911164
自定义分词器：https://blog.csdn.net/m0_57302315/article/details/121103241
Canal胶水层：https://gitee.com/throwableDoge/canal-glue

rocketmq

1. mq maven依赖

            <dependency>
                <groupId>org.apache.rocketmq</groupId>
                <artifactId>rocketmq-spring-boot-starter</artifactId>
                <version>2.2.0</version>
            </dependency>

2. mq 适配器

import lombok.RequiredArgsConstructor;
import org.apache.rocketmq.client.producer.DefaultMQProducer;
import org.apache.rocketmq.spring.core.RocketMQTemplate;
import org.apache.rocketmq.spring.support.RocketMQMessageConverter;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Configuration;

/**
 * @author gideon
 */
@Configuration
@RequiredArgsConstructor
public class RocketMqAdapter {

    private final RocketMQMessageConverter rocketMqMessageConverter;

    @Value("${rocketmq.name-server:}")
    private String nameServer;

    public RocketMQTemplate getTemplateByTopicName(String topic){
        RocketMQTemplate mqTemplate = new RocketMQTemplate();
        DefaultMQProducer producer = new DefaultMQProducer(topic);
        producer.setNamesrvAddr(nameServer);
        producer.setRetryTimesWhenSendFailed(2);
        producer.setSendMsgTimeout((int) RocketMqConstant.TIMEOUT);
        mqTemplate.setProducer(producer);
        mqTemplate.setMessageConverter(rocketMqMessageConverter.getMessageConverter());
        return mqTemplate;
    }

}

3. mq的一些常量信息RocketMqConstant

/**
 * nameserver用;分割
 * 同步消息，如果两次
 */
public class RocketMqConstant {

    // 延迟消息 1s 5s 10s 30s 1m 2m 3m 4m 5m 6m 7m 8m 9m 10m 20m 30m 1h 2h (1-18)

    /**
     * 自动收货时间，实际上7天
     */
    public static final int ORDER_AUTO_RECEIPT_DELAY_LEVEL = 60 * 24 * 7;

    /**
     * 默认发送消息超时时间
     */
    public static final long TIMEOUT = 3000;


    /**
     * 订单取消退款
     */
    public static final String ORDER_REFUND_TOPIC = "order-refund-topic";

    /**
     * 订单自动收货
     */
    public static final String AUTO_RECEIPT_TOPIC = "auto-receipt-topic";

    /**
     * 服务订单订单支付成功
     */
    public static final String ORDER_NOTIFY_TOPIC = "order-notify-topic";

    /**
     * canal-topic
     */
    public static final String CANAL_TOPIC = "canal-topic";

}

4. mq的配置类

import com.onecode.dtg.basic.RocketMqAdapter;
import com.onecode.dtg.basic.RocketMqConstant;
import lombok.RequiredArgsConstructor;
import org.apache.rocketmq.spring.core.RocketMQTemplate;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.context.annotation.Lazy;

/**
 * @author gideon
 */
@Configuration
@RequiredArgsConstructor
public class RocketMqConfig {

    private final RocketMqAdapter rocketMqAdapter;

    @Lazy
    @Bean(destroyMethod = "destroy")
    public RocketMQTemplate autoReceiptTemplate() {
        return rocketMqAdapter.getTemplateByTopicName(RocketMqConstant.AUTO_RECEIPT_TOPIC);
    }
}

5. mq 的配置文件信息

rocketmq:
  name-server: 127.0.0.1:9876

elasticsearch

elasticsearch的搭建我在这里就不不多bb了，你们自行百度，下面是资料。

1. maven所需依赖

 	</properties>
        <elasticsearch.version>7.9.1</elasticsearch.version>
    </properties>
      <dependencies>
            <dependency>
                <groupId>org.elasticsearch.client</groupId>
                <artifactId>elasticsearch-rest-high-level-client</artifactId>
                <version>${elasticsearch.version}</version>
            </dependency>
            <dependency>
                <groupId>org.elasticsearch</groupId>
                <artifactId>elasticsearch</artifactId>
                <version>${elasticsearch.version}</version>
            </dependency>
            <dependency>
                <groupId>org.elasticsearch.client</groupId>
                <artifactId>elasticsearch-rest-client</artifactId>
                <version>${elasticsearch.version}</version>
                <exclusions>
                    <exclusion>
                        <artifactId>commons-logging</artifactId>
                        <groupId>commons-logging</groupId>
                    </exclusion>
                </exclusions>
            </dependency>
          </dependencies>

2. 分词所需资料 elasticsearch搭建的资料，点击这里。
3. elasticsearch的yml

# elastic的地址
elastic:
  hostname: 127.0.0.1
  port: 9200

4. elasticsearch 启动配置类

import lombok.RequiredArgsConstructor;
import org.apache.http.HttpHost;
import org.elasticsearch.client.RestClient;
import org.elasticsearch.client.RestHighLevelClient;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

/**
 * @author gideon
 */
@Configuration
@RequiredArgsConstructor
public class ElasticConfig {


    @Value("${elastic.hostname}")
    private String hostname;

    @Value("${elastic.port}")
    private int port;

    @Bean
    public RestHighLevelClient restHighLevelClient() {
        return new RestHighLevelClient(
                RestClient.builder(
                        new HttpHost(hostname, port)));
    }
}

5. elasticsearch 自定义注解，AnalyzerType在下面。

import java.lang.annotation.*;

/**
 * @author gideon
 * @date 2022/9/8
 */
@Retention(RetentionPolicy.RUNTIME)
@Target(ElementType.FIELD)
@Documented
@Inherited
public @interface EsField {

    FieldType type() default FieldType.TEXT;

    /**
     * 指定分词器
     *
     * @return AnalyzerType
     */
    AnalyzerType analyzer() default AnalyzerType.STANDARD;
}

6. elasticsearch 自定义AnalyzerType，因为我自己的业务需要所以我加了一个自定义分词器comma

import lombok.Getter;

/**
 * @author gideon
 * @date 2022/9/8
 */
@Getter
public enum AnalyzerType {

    /**
     * 不使用分词
     */
    NO("不使用分词"),
    /**
     * 标准分词，默认分词器
     */
    STANDARD("standard"),

    /**
     * ik_smart：会做最粗粒度的拆分；已被分出的词语将不会再次被其它词语占有
     */
    IK_SMART("ik_smart"),

    /**
     * ik_max_word ：会将文本做最细粒度的拆分；尽可能多的拆分出词语
     */
    IK_MAX_WORD("ik_max_word"),

    /**
     * ik_max_word ：会将文本做逗号分词
     */
    COMMA("comma"),
    ;

    private final String type;

    AnalyzerType(String type) {
        this.type = type;
    }

}

7. elasticsearch 自定义FieldType

import lombok.Getter;

/**
 * @author gideon
 * @date 2022/9/8
 */
@Getter
public enum FieldType {
    /**
     *
     */
    TEXT("text"),

    KEYWORD("keyword"),

    INTEGER("integer"),

    DOUBLE("double"),

    DATE("date"),

    LONG("long"),

    /**
     * 单条数据
     */
    OBJECT("object"),

    /**
     * 嵌套数组
     */
    NESTED("nested"),
    ;

    FieldType(String type){
        this.type = type;
    }

    private final String type;
}

8. elasticsearch索引名称枚举

/**
 * es当中的index
 *
 * @author gideon
 */
public enum EsIndexEnum {

    /**
     * 护理员
     */
    SERVER("server"),

    ;

    private final String value;

    public String value() {
        return value;
    }

    EsIndexEnum(String value) {
        this.value = value;
    }
}

9. elasticsearch 创建索引代码EsIndexCreateService，CommonBizException是我自定义的异常，你们可以使用自己自定义的异常类。

import com.onecode.dtg.basic.common.enums.ResultCode;
import com.onecode.dtg.basic.common.es.annotation.EsField;
import com.onecode.dtg.basic.common.es.enums.FieldType;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.elasticsearch.client.RequestOptions;
import org.elasticsearch.client.RestHighLevelClient;
import org.elasticsearch.client.indices.CreateIndexRequest;
import org.elasticsearch.client.indices.CreateIndexResponse;
import org.elasticsearch.client.indices.GetIndexRequest;
import org.elasticsearch.common.xcontent.XContentBuilder;
import org.elasticsearch.common.xcontent.XContentFactory;
import org.springframework.stereotype.Service;

import java.io.IOException;
import java.lang.reflect.Field;

/**
 * @author gideon
 * @date 2022/9/8
 */
@Slf4j
@Service
@RequiredArgsConstructor
public class EsIndexCreateService {

    private final RestHighLevelClient restHighLevelClient;

    /**
     * 不需要逗号分词器索引
     *
     * @param indexName 索引名称
     * @param clazz     同步到es的实体类
     * @return boolean
     */
    public boolean createIndex(String indexName, Class<?> clazz) {
        return createIndex(indexName, clazz, false);
    }

    /**
     * 建立索引
     *
     * @param indexName 索引名称
     * @param comma     是否需要逗号分词器
     * @return boolean
     */
    public boolean createIndex(String indexName, Class<?> clazz, Boolean comma) {
        try {
//            判断索引是否存在
            GetIndexRequest getIndexRequest = new GetIndexRequest(indexName);
            boolean exists = restHighLevelClient.indices().exists(getIndexRequest, RequestOptions.DEFAULT);
            if (exists) {
                return true;
            }
            CreateIndexRequest request = new CreateIndexRequest(indexName);

            if (comma) {
                XContentBuilder settingsBuilder = XContentFactory.jsonBuilder()
                        .startObject()
                        .startObject("analysis")
                        .startObject("analyzer")
                        .startObject("comma")
                        .field("type", "pattern")
//                        将分词器规则定义为按照","进行分词
                        .field("pattern", ",")
                        .endObject()
                        .endObject()
                        .endObject()
                        .endObject();
                request.settings(settingsBuilder);
            }

//            这里创建索引结构
            request.mapping(generateBuilder(clazz));
            CreateIndexResponse response = restHighLevelClient.indices().create(request, RequestOptions.DEFAULT);
//            指示是否所有节点都已确认请求
            boolean acknowledged = response.isAcknowledged();
//            指示是否在超时之前为索引中的每个分片启动了必需的分片副本数
            boolean shardsAcknowledged = response.isShardsAcknowledged();
            if (acknowledged || shardsAcknowledged) {
                log.info("创建索引成功！索引名称为{}", indexName);
                return true;
            }
            return false;
        } catch (IOException e) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引：" + indexName + "失败。");
        }
    }


    /**
     * 生成es索引
     *
     * @param clazz 对于的es实体
     * @return XContentBuilder
     */
    public static XContentBuilder generateBuilder(Class<?> clazz) {
        try {
//        获取索引名称及类型
            XContentBuilder builder = XContentFactory.jsonBuilder();
            builder.startObject();
            builder.startObject("properties");
            Field[] declaredFields = clazz.getDeclaredFields();
            for (Field declaredField : declaredFields) {
                if (declaredField.isAnnotationPresent(EsField.class)) {
//                获取注解
                    EsField declaredAnnotation = declaredField.getDeclaredAnnotation(EsField.class);
//                        如果嵌套对象
                    /**
                     * {
                     *   "mappings": {
                     *     "properties": {
                     *       "region": {
                     *         "type": "keyword"
                     *       },
                     *       "manager": {
                     *         "properties": {
                     *           "age":  { "type": "integer" },
                     *           "name": {
                     *             "properties": {
                     *               "first": { "type": "text" },
                     *               "last":  { "type": "text" }
                     *             }
                     *           }
                     *         }
                     *       }
                     *     }
                     *   }
                     * }
                     */
                    if (declaredAnnotation.type() == FieldType.OBJECT) {
//                    获取当前类的对象-- Action
                        Class<?> type = declaredField.getType();
                        Field[] typeDeclaredFields = type.getDeclaredFields();
                        builder.startObject(declaredField.getName());
                        builder.startObject("properties");
//                    遍历该对象中的所有属性
                        for (Field field : typeDeclaredFields) {
                            if (field.isAnnotationPresent(EsField.class)) {
//                            获取注解
                                EsField fieldDeclaredAnnotation = field.getDeclaredAnnotation(EsField.class);
                                builder.startObject(field.getName());
                                builder.field("type", fieldDeclaredAnnotation.type().getType());
//                            keyword不需要分词
                                if (fieldDeclaredAnnotation.type() == FieldType.TEXT) {
                                    builder.field("analyzer", fieldDeclaredAnnotation.analyzer().getType());
                                }
                                builder.endObject();
                            }
                        }
                        builder.endObject();
                        builder.endObject();

                    } else {
                        builder.startObject(declaredField.getName());
                        builder.field("type", declaredAnnotation.type().getType());
//                        keyword不需要分词
                        if (declaredAnnotation.type() == FieldType.TEXT) {
                            builder.field("analyzer", declaredAnnotation.analyzer().getType());
                        }
                        builder.endObject();
                    }
                }
            }
//            对应property
            builder.endObject();
            builder.endObject();
            return builder;
        } catch (IOException e) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引失败。");
        }
    }
}

canal

因为我这里使用的是第三方的canal jar包，也就是上面说到的Canal胶水层
获取地址：https://gitee.com/gz-yami/mall4cloud/tree/master/mall4cloud-common/mall4cloud-common-core/lib
引入的maven

		<dependency>
			<groupId>cn.throwx</groupId>
			<artifactId>canal-glue-core</artifactId>
			<version>1.0</version>
			<scope>system</scope>
			<systemPath>${pom.basedir}/lib/canal-glue-core.jar</systemPath>
		</dependency>

类似于下面这样放

1. canal的canal.properties配置文件信息，这里主要看你使用什么信息队列就配置什么。我使用的是RocketMQ，然后需要创建一个topic去监听数据库的操作日志，配置topic在rocketmq.producer.group = canal-topic

#################################################
######### 		common argument		#############
#################################################
# tcp bind ip
canal.ip =
# register ip to zookeeper
canal.register.ip =
canal.port = 11111
canal.metrics.pull.port = 11112
# canal instance user/passwd
# canal.user = canal
# canal.passwd = E3619321C1A937C46A0D8BD1DAC39F93B27D4458

# canal admin config
#canal.admin.manager = 127.0.0.1:8089
canal.admin.port = 11110
canal.admin.user = admin
canal.admin.passwd = 4ACFE3202A5FF5CF467898FC58AAB1D615029441
# admin auto register
#canal.admin.register.auto = true
#canal.admin.register.cluster =
#canal.admin.register.name =

canal.zkServers =
# flush data to zk
canal.zookeeper.flush.period = 1000
canal.withoutNetty = false
# tcp, kafka, rocketMQ, rabbitMQ
canal.serverMode = rocketMQ
# flush meta cursor/parse position to file
canal.file.data.dir = ${canal.conf.dir}
canal.file.flush.period = 1000
## memory store RingBuffer size, should be Math.pow(2,n)
canal.instance.memory.buffer.size = 16384
## memory store RingBuffer used memory unit size , default 1kb
canal.instance.memory.buffer.memunit = 1024
## meory store gets mode used MEMSIZE or ITEMSIZE
canal.instance.memory.batch.mode = MEMSIZE
canal.instance.memory.rawEntry = true

## detecing config
canal.instance.detecting.enable = false
#canal.instance.detecting.sql = insert into retl.xdual values(1,now()) on duplicate key update x=now()
canal.instance.detecting.sql = select 1
canal.instance.detecting.interval.time = 3
canal.instance.detecting.retry.threshold = 3
canal.instance.detecting.heartbeatHaEnable = false

# support maximum transaction size, more than the size of the transaction will be cut into multiple transactions delivery
canal.instance.transaction.size =  1024
# mysql fallback connected to new master should fallback times
canal.instance.fallbackIntervalInSeconds = 60

# network config
canal.instance.network.receiveBufferSize = 16384
canal.instance.network.sendBufferSize = 16384
canal.instance.network.soTimeout = 30

# binlog filter config
canal.instance.filter.druid.ddl = true
canal.instance.filter.query.dcl = false
canal.instance.filter.query.dml = false
canal.instance.filter.query.ddl = false
canal.instance.filter.table.error = false
canal.instance.filter.rows = false
canal.instance.filter.transaction.entry = false
canal.instance.filter.dml.insert = false
canal.instance.filter.dml.update = false
canal.instance.filter.dml.delete = false

# binlog format/image check
canal.instance.binlog.format = ROW,STATEMENT,MIXED
canal.instance.binlog.image = FULL,MINIMAL,NOBLOB

# binlog ddl isolation
canal.instance.get.ddl.isolation = false

# parallel parser config
canal.instance.parser.parallel = true
## concurrent thread number, default 60% available processors, suggest not to exceed Runtime.getRuntime().availableProcessors()
#canal.instance.parser.parallelThreadSize = 16
## disruptor ringbuffer size, must be power of 2
canal.instance.parser.parallelBufferSize = 256

# table meta tsdb info
canal.instance.tsdb.enable = true
canal.instance.tsdb.dir = ${canal.file.data.dir:../conf}/${canal.instance.destination:}
canal.instance.tsdb.url = jdbc:h2:${canal.instance.tsdb.dir}/h2;CACHE_SIZE=1000;MODE=MYSQL;
canal.instance.tsdb.dbUsername = canal
canal.instance.tsdb.dbPassword = canal
# dump snapshot interval, default 24 hour
canal.instance.tsdb.snapshot.interval = 24
# purge snapshot expire , default 360 hour(15 days)
canal.instance.tsdb.snapshot.expire = 360

#################################################
######### 		destinations		#############
#################################################
canal.destinations = example
# conf root dir
canal.conf.dir = ../conf
# auto scan instance dir add/remove and start/stop instance
canal.auto.scan = true
canal.auto.scan.interval = 5
# set this value to 'true' means that when binlog pos not found, skip to latest.
# WARN: pls keep 'false' in production env, or if you know what you want.
canal.auto.reset.latest.pos.mode = false

canal.instance.tsdb.spring.xml = classpath:spring/tsdb/h2-tsdb.xml
#canal.instance.tsdb.spring.xml = classpath:spring/tsdb/mysql-tsdb.xml

canal.instance.global.mode = spring
canal.instance.global.lazy = false
canal.instance.global.manager.address = ${canal.admin.manager}
#canal.instance.global.spring.xml = classpath:spring/memory-instance.xml
canal.instance.global.spring.xml = classpath:spring/file-instance.xml
#canal.instance.global.spring.xml = classpath:spring/default-instance.xml

##################################################
######### 	      MQ Properties      #############
##################################################
# aliyun ak/sk , support rds/mq
canal.aliyun.accessKey =
canal.aliyun.secretKey =
canal.aliyun.uid=

canal.mq.flatMessage = true
canal.mq.canalBatchSize = 50
canal.mq.canalGetTimeout = 100
# Set this value to "cloud", if you want open message trace feature in aliyun.
canal.mq.accessChannel = local

canal.mq.database.hash = true
canal.mq.send.thread.size = 30
canal.mq.build.thread.size = 8

##################################################
######### 		     Kafka 		     #############
##################################################
kafka.bootstrap.servers = 127.0.0.1:9092
kafka.acks = all
kafka.compression.type = none
kafka.batch.size = 16384
kafka.linger.ms = 1
kafka.max.request.size = 1048576
kafka.buffer.memory = 33554432
kafka.max.in.flight.requests.per.connection = 1
kafka.retries = 0

kafka.kerberos.enable = false
kafka.kerberos.krb5.file = "../conf/kerberos/krb5.conf"
kafka.kerberos.jaas.file = "../conf/kerberos/jaas.conf"

##################################################
######### 		    RocketMQ	     #############
##################################################
rocketmq.producer.group = canal-topic
rocketmq.enable.message.trace = false
rocketmq.customized.trace.topic =
rocketmq.namespace =
rocketmq.namesrv.addr = 192.168.1.46:9876
rocketmq.retry.times.when.send.failed = 3
rocketmq.vip.channel.enabled = false
rocketmq.tag =

##################################################
######### 		    RabbitMQ	     #############
##################################################
rabbitmq.host =
rabbitmq.virtual.host =
rabbitmq.exchange =
rabbitmq.username =
rabbitmq.password =
rabbitmq.deliveryMode =

2. canal的instance.properties配置文件信息，canal.instance.filter.regex这个参数可以指定监听的数据库->表

#################################################
## mysql serverId , v1.0.26+ will autoGen
# canal.instance.mysql.slaveId=0

# enable gtid use true/false
canal.instance.gtidon=false

# position info
canal.instance.master.address=192.168.1.46:3306
canal.instance.master.journal.name=mysql-binlog.000001
canal.instance.master.position=0
canal.instance.master.timestamp=
canal.instance.master.gtid=

# rds oss binlog
canal.instance.rds.accesskey=
canal.instance.rds.secretkey=
canal.instance.rds.instanceId=

# table meta tsdb info
canal.instance.tsdb.enable=false
#canal.instance.tsdb.url=jdbc:mysql://127.0.0.1:3306/canal_tsdb
#canal.instance.tsdb.dbUsername=canal
#canal.instance.tsdb.dbPassword=canal

#canal.instance.standby.address =
#canal.instance.standby.journal.name =
#canal.instance.standby.position =
#canal.instance.standby.timestamp =
#canal.instance.standby.gtid=

# username/password
canal.instance.dbUsername=canal
canal.instance.dbPassword=canal
canal.instance.connectionCharset = UTF-8
# enable druid Decrypt database password
canal.instance.enableDruid=false
#canal.instance.pwdPublicKey=MFwwDQYJKoZIhvcNAQEBBQADSwAwSAJBALK4BUxdDltRRE5/zXpVEVPUgunvscYFtEip3pmLlhrWpacX7y7GCMo2/JM6LeHmiiNdH1FWgGCpUfircSwlWKUCAwEAAQ==

# table regex
canal.instance.filter.regex=mp_biz_service.server:*,mp_biz_service.shop_service_server:*
# table black regex
canal.instance.filter.black.regex=mysql\\.slave_.*
# table field filter(format: schema1.tableName1:field1/field2,schema2.tableName2:field1/field2)
#canal.instance.filter.field=test1.t_product:id/subject/keywords,test2.t_company:id/name/contact/ch
# table field black filter(format: schema1.tableName1:field1/field2,schema2.tableName2:field1/field2)
#canal.instance.filter.black.field=test1.t_product:subject/product_image,test2.t_company:id/name/contact/ch

# mq config
canal.mq.topic=canal-topic
# dynamic topic route by schema or table regex
#canal.mq.dynamicTopic=mytest1.user,mytest2\\..*,.*\\..*
canal.mq.partition=0
# hash partition config
#canal.mq.partitionsNum=3
#canal.mq.partitionHash=test.table:id^name,.*\\..*
#canal.mq.dynamicTopicPartitionNum=test.*:4,mycanal:6
#################################################

3. canal自定义处理器NdCanalBinLogEventParser

import cn.throwx.canal.gule.common.BinLogEventType;
import cn.throwx.canal.gule.common.OperationType;
import cn.throwx.canal.gule.model.CanalBinLogEvent;
import cn.throwx.canal.gule.model.CanalBinLogResult;
import cn.throwx.canal.gule.support.parser.BaseCommonEntryFunction;
import cn.throwx.canal.gule.support.parser.BasePrimaryKeyTupleFunction;
import cn.throwx.canal.gule.support.parser.CanalBinLogEventParser;
import com.alibaba.fastjson.JSON;
import lombok.extern.slf4j.Slf4j;

import java.util.*;

/**
 * @author gideon
 */
@Slf4j
public class NdCanalBinLogEventParser implements CanalBinLogEventParser {

    @Override
    public <T> List<CanalBinLogResult<T>> parse(CanalBinLogEvent event, Class<T> klass, BasePrimaryKeyTupleFunction primaryKeyFunction, BaseCommonEntryFunction<T> commonEntryFunction) {
        BinLogEventType eventType = BinLogEventType.fromType(event.getType());
        if (Objects.equals(BinLogEventType.CREATE, eventType) || Objects.equals(BinLogEventType.ALTER, eventType)) {
            if (log.isDebugEnabled()) {
                log.debug("监听到不需要处理或者未知的binlog事件类型[{}],将忽略解析过程返回空列表,binlog事件:{}", eventType, JSON.toJSONString(event));
            }
            return Collections.emptyList();
        }

        if (BinLogEventType.UNKNOWN != eventType && BinLogEventType.QUERY != eventType) {
            if (Boolean.TRUE.equals(event.getIsDdl())) {
                CanalBinLogResult<T> entry = new CanalBinLogResult<>();
                entry.setOperationType(OperationType.DDL);
                entry.setBinLogEventType(eventType);
                entry.setDatabaseName(event.getDatabase());
                entry.setTableName(event.getTable());
                entry.setSql(event.getSql());
                return Collections.singletonList(entry);
            } else {
                Optional.ofNullable(event.getPkNames()).filter((x) -> x.size() == 1).orElseThrow(() -> new IllegalArgumentException("DML类型binlog事件主键列数量不为1"));
                String primaryKeyName = event.getPkNames().get(0);
                List<CanalBinLogResult<T>> entryList = new LinkedList<>();
                List<Map<String, String>> data = event.getData();
                List<Map<String, String>> old = event.getOld();
                int dataSize = null != data ? data.size() : 0;
                int oldSize = null != old ? old.size() : 0;
                if (dataSize > 0) {
                    for(int index = 0; index < dataSize; ++index) {
                        CanalBinLogResult<T> entry = new CanalBinLogResult<>();
                        entryList.add(entry);
                        entry.setSql(event.getSql());
                        entry.setOperationType(OperationType.DML);
                        entry.setBinLogEventType(eventType);
                        entry.setTableName(event.getTable());
                        entry.setDatabaseName(event.getDatabase());
                        Map<String, String> item = data.get(index);
                        entry.setAfterData(commonEntryFunction.apply(item));
                        Map<String, String> oldItem = null;
                        if (oldSize > 0 && index <= oldSize) {
                            oldItem = old.get(index);
                            entry.setBeforeData(commonEntryFunction.apply(oldItem));
                        }

                        entry.setPrimaryKey(primaryKeyFunction.apply(oldItem, item, primaryKeyName));
                    }
                }

                return entryList;
            }
        } else {
            if (log.isDebugEnabled()) {
                log.debug("监听到不需要处理或者未知的binlog事件类型[{}],将忽略解析过程返回空列表,binlog事件:{}", eventType, JSON.toJSONString(event));
            }

            return Collections.emptyList();
        }
    }

    private NdCanalBinLogEventParser() {
    }

    public static NdCanalBinLogEventParser of() {
        return new NdCanalBinLogEventParser();
    }
}

4. canal自定义处理器NdCanalBinlogEventProcessorFactory

import cn.throwx.canal.gule.model.ModelTable;
import cn.throwx.canal.gule.support.processor.BaseCanalBinlogEventProcessor;
import cn.throwx.canal.gule.support.processor.CanalBinlogEventProcessorFactory;

import java.util.LinkedList;
import java.util.List;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.ConcurrentMap;

/**
 * @author gideon
 */
public class NdCanalBinlogEventProcessorFactory implements CanalBinlogEventProcessorFactory {

    private final ConcurrentMap<ModelTable, List<BaseCanalBinlogEventProcessor<?>>> cache = new ConcurrentHashMap<>(16);

    @Override
    public void register(ModelTable modelTable, BaseCanalBinlogEventProcessor<?> processor) {
        synchronized(this.cache) {
            this.cache.putIfAbsent(modelTable, new LinkedList<>());
            this.cache.get(modelTable).add(processor);
        }
    }

    @Override
    public List<BaseCanalBinlogEventProcessor<?>> get(ModelTable modelTable) {
        return this.cache.get(modelTable);
    }

    private NdCanalBinlogEventProcessorFactory() {
    }

    public static NdCanalBinlogEventProcessorFactory of() {
        return new NdCanalBinlogEventProcessorFactory();
    }
}

5. canal自定义处理器NdCanalGlue

import cn.throwx.canal.gule.CanalGlue;
import cn.throwx.canal.gule.model.CanalBinLogEvent;
import cn.throwx.canal.gule.model.ModelTable;
import cn.throwx.canal.gule.support.adapter.SourceAdapterFacade;
import cn.throwx.canal.gule.support.processor.BaseCanalBinlogEventProcessor;
import cn.throwx.canal.gule.support.processor.CanalBinlogEventProcessorFactory;

import java.util.List;

/**
 * @author gideon
 */
public class NdCanalGlue implements CanalGlue {

    private final CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory;

    @Override
    public void process(String content) {
        CanalBinLogEvent event = SourceAdapterFacade.X.adapt(CanalBinLogEvent.class, content);
        ModelTable modelTable = ModelTable.of(event.getDatabase(), event.getTable());
        List<BaseCanalBinlogEventProcessor<?>> baseCanalBinlogEventProcessors = this.canalBinlogEventProcessorFactory.get(modelTable);
        if (baseCanalBinlogEventProcessors.isEmpty()) {
            return;
        }
        baseCanalBinlogEventProcessors.forEach((processor) -> processor.process(event));
    }


    private NdCanalGlue(CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory) {
        this.canalBinlogEventProcessorFactory = canalBinlogEventProcessorFactory;
    }

    public static NdCanalGlue of(CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory) {
        return new NdCanalGlue(canalBinlogEventProcessorFactory);
    }
}

6. canal配置类

import cn.throwx.canal.gule.CanalGlue;
import cn.throwx.canal.gule.support.parser.*;
import cn.throwx.canal.gule.support.parser.converter.CanalFieldConverterFactory;
import cn.throwx.canal.gule.support.parser.converter.InMemoryCanalFieldConverterFactory;
import cn.throwx.canal.gule.support.processor.BaseCanalBinlogEventProcessor;
import cn.throwx.canal.gule.support.processor.CanalBinlogEventProcessorFactory;
import com.onecode.middle.search.service.canal.NdCanalBinLogEventParser;
import com.onecode.middle.search.service.canal.NdCanalBinlogEventProcessorFactory;
import com.onecode.middle.search.service.canal.NdCanalGlue;
import org.springframework.beans.BeansException;
import org.springframework.beans.factory.BeanFactory;
import org.springframework.beans.factory.BeanFactoryAware;
import org.springframework.beans.factory.SmartInitializingSingleton;
import org.springframework.beans.factory.config.ConfigurableListableBeanFactory;
import org.springframework.boot.autoconfigure.condition.ConditionalOnMissingBean;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.context.annotation.Primary;

import java.util.Map;

/**
 * @author gideon
 */
@Configuration
public class CanalGlueAutoConfiguration implements SmartInitializingSingleton, BeanFactoryAware {

    private ConfigurableListableBeanFactory configurableListableBeanFactory;

    @Bean
    @ConditionalOnMissingBean
    public CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory() {
        return NdCanalBinlogEventProcessorFactory.of();
    }

    @Bean
    @ConditionalOnMissingBean
    public ModelTableMetadataManager modelTableMetadataManager(CanalFieldConverterFactory canalFieldConverterFactory) {
        return InMemoryModelTableMetadataManager.of(canalFieldConverterFactory);
    }

    @Bean
    @ConditionalOnMissingBean
    public CanalFieldConverterFactory canalFieldConverterFactory() {
        return InMemoryCanalFieldConverterFactory.of();
    }

    @Bean
    @ConditionalOnMissingBean
    public CanalBinLogEventParser canalBinLogEventParser() {
        return NdCanalBinLogEventParser.of();
    }

    @Bean
    @ConditionalOnMissingBean
    public ParseResultInterceptorManager parseResultInterceptorManager(ModelTableMetadataManager modelTableMetadataManager) {
        return InMemoryParseResultInterceptorManager.of(modelTableMetadataManager);
    }

    @Bean
    @Primary
    public CanalGlue canalGlue(CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory) {
        return NdCanalGlue.of(canalBinlogEventProcessorFactory);
    }

    @Override
    public void setBeanFactory(BeanFactory beanFactory) throws BeansException {
        this.configurableListableBeanFactory = (ConfigurableListableBeanFactory) beanFactory;
    }

    @SuppressWarnings({"rawtypes", "unchecked"})
    @Override
    public void afterSingletonsInstantiated() {
        ParseResultInterceptorManager parseResultInterceptorManager
                = configurableListableBeanFactory.getBean(ParseResultInterceptorManager.class);
        ModelTableMetadataManager modelTableMetadataManager
                = configurableListableBeanFactory.getBean(ModelTableMetadataManager.class);
        CanalBinlogEventProcessorFactory canalBinlogEventProcessorFactory
                = configurableListableBeanFactory.getBean(CanalBinlogEventProcessorFactory.class);
        CanalBinLogEventParser canalBinLogEventParser
                = configurableListableBeanFactory.getBean(CanalBinLogEventParser.class);
        Map<String, BaseParseResultInterceptor> interceptors
                = configurableListableBeanFactory.getBeansOfType(BaseParseResultInterceptor.class);
        interceptors.forEach((k, interceptor) -> parseResultInterceptorManager.registerParseResultInterceptor(interceptor));
        Map<String, BaseCanalBinlogEventProcessor> processors
                = configurableListableBeanFactory.getBeansOfType(BaseCanalBinlogEventProcessor.class);
        processors.forEach((k, processor) -> processor.init(canalBinLogEventParser, modelTableMetadataManager,
                canalBinlogEventProcessorFactory, parseResultInterceptorManager));
    }
}

6. ServerBO canal转换的实体类，@CanalModel 的参数database是对应的数据库，table是对应数据库下的数据表，因为这个数据是需要同步到es的所以设置了类型。

import cn.throwx.canal.gule.annotation.CanalModel;
import cn.throwx.canal.gule.common.FieldNamingPolicy;
import com.fasterxml.jackson.annotation.JsonFormat;
import com.onecode.dtg.basic.common.es.annotation.EsField;
import com.onecode.dtg.basic.common.es.enums.AnalyzerType;
import com.onecode.dtg.basic.common.es.enums.FieldType;
import io.swagger.annotations.ApiModelProperty;
import lombok.Data;

import java.time.LocalDate;
import java.time.LocalDateTime;

/**
 * @author gideon
 */
@Data
@CanalModel(database = "mp_biz_service", table = "server", fieldNamingPolicy = FieldNamingPolicy.LOWER_UNDERSCORE)
public class ServerBO {

    @ApiModelProperty("id")
    @EsField(type = FieldType.LONG)
    private Long id;

    @ApiModelProperty("用户标识")
    @EsField(type = FieldType.LONG)
    private Long userId;

    @ApiModelProperty("类型")
    @EsField(type = FieldType.KEYWORD)
    private String type;

    @ApiModelProperty("姓名")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String name;

    @ApiModelProperty("值为1时是男性，值为2时是女性，值为0时是未知")
    @EsField(type = FieldType.KEYWORD)
    private String gender;

    @ApiModelProperty("出生年月日")
    @JsonFormat(pattern = "yyyy-MM-dd")
    @EsField(type = FieldType.DATE)
    private LocalDate birthday;

    @ApiModelProperty("学历")
    @EsField(type = FieldType.KEYWORD)
    private String education;

    @ApiModelProperty("从业时间")
    @JsonFormat(pattern = "yyyy-MM-dd")
    @EsField(type = FieldType.DATE)
    private LocalDate practiceDate;

    @ApiModelProperty("评级")
    @EsField(type = FieldType.KEYWORD)
    private String level;

    @ApiModelProperty("认证标签")
    @EsField(type = FieldType.TEXT)
    private String authLabel;

    @ApiModelProperty("勋章（逗号隔开）")
    @EsField(type = FieldType.TEXT)
    private String medal;

    @ApiModelProperty("服务评分")
    @EsField(type = FieldType.INTEGER)
    private Integer serviceScore;

    @ApiModelProperty("已实名认证")
    @EsField(type = FieldType.INTEGER)
    private Integer realNameAuth;

    @ApiModelProperty("身份证号")
    @EsField(type = FieldType.TEXT)
    private String idCardNo;

    @ApiModelProperty("户籍-省")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String idCardProvince;

    @ApiModelProperty("户籍-市")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String idCardCity;

    @ApiModelProperty("户籍-区")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String idCardRegion;

    @ApiModelProperty("手机号")
    @EsField(type = FieldType.TEXT)
    private String phone;

    @ApiModelProperty("现住-省")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String presentProvince;

    @ApiModelProperty("现住-市")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String presentCity;

    @ApiModelProperty("现住-区")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String presentRegion;

    @ApiModelProperty("现住-地址")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String presentAddress;

    @ApiModelProperty("头像")
    @EsField(type = FieldType.TEXT)
    private String head;

    @ApiModelProperty("使用状态（初始化：init;正常：normal，禁用：ban）")
    @EsField(type = FieldType.KEYWORD)
    private String useStatus;

    @ApiModelProperty("审核状态 （待审核：await;通过：pass，驳回：reject）")
    @EsField(type = FieldType.KEYWORD)
    private String auditStatus;

    @ApiModelProperty("驳回理由")
    @EsField(type = FieldType.TEXT)
    private String rejectReason;

    @ApiModelProperty("注册时间")
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    @EsField(type = FieldType.DATE)
    private LocalDateTime regDate;

    @ApiModelProperty("介绍-内容")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String introContent;

    @ApiModelProperty("介绍-视频")
    @EsField(type = FieldType.TEXT)
    private String introVideo;

    @ApiModelProperty("介绍-标签")
    @EsField(type = FieldType.TEXT)
    private String introLabel;

    @ApiModelProperty("商家标识")
    @EsField(type = FieldType.LONG)
    private Long merchantId;

    @ApiModelProperty("组织标识")
    @EsField(type = FieldType.LONG)
    private Long orgId;

    @ApiModelProperty("护理员申请sku，多个逗号隔开")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.COMMA)
    private String skuId;

    @ApiModelProperty("护理员排班数据，多个逗号隔开")
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.COMMA)
    private String schedule;

    /**
     * 逻辑删除
     */
    @EsField(type = FieldType.INTEGER)
    private Integer del;

    /**
     * 创建人
     */
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String createBy;

    /**
     * 创建时间
     */
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    @EsField(type = FieldType.DATE)
    private LocalDateTime createTime;

    /**
     * 更新者
     */
    @EsField(type = FieldType.TEXT, analyzer = AnalyzerType.IK_SMART)
    private String updateBy;

    /**
     * 更新时间
     */
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    @EsField(type = FieldType.DATE)
    private LocalDateTime updateTime;

}

7. ShopServiceServer canal转换的实体类，@CanalModel 的参数database是对应的数据库，table是对应数据库下的数据表

import cn.throwx.canal.gule.annotation.CanalModel;
import cn.throwx.canal.gule.common.FieldNamingPolicy;
import io.swagger.annotations.ApiModelProperty;
import lombok.Data;

import java.time.LocalDateTime;

/**
 * @author gideon
 */
@Data
@CanalModel(database = "mp_biz_service", table = "shop_service_server", fieldNamingPolicy = FieldNamingPolicy.LOWER_UNDERSCORE)
public class ShopServiceServerBO {
    @ApiModelProperty("ID")
    private Long id;

    @ApiModelProperty("产品标识")
    private Long productId;

    @ApiModelProperty("服务者用户标识")
    private Long serverUserId;

    @ApiModelProperty("产品sku标识")
    private Long productSkuId;

    @ApiModelProperty(value = "盈利")
    private Integer profit;

    @ApiModelProperty("商家标识")
    private Long merchantId;

    @ApiModelProperty("组织标识")
    private Long orgId;

    /**
     * 逻辑删除
     */
    private Integer del;

    /**
     * 创建人
     */
    private String createBy;

    /**
     * 创建时间
     */
    private LocalDateTime createTime;

    /**
     * 更新者
     */
    private String updateBy;

    /**
     * 更新时间
     */
    private LocalDateTime updateTime;
}

9. 至此canal的基础代码就完成。

消费MQ订阅的canal信息，进行elasticsearch的同步以及搜索

1. 监听我们上面canal-topic订阅的消息然后进行同步数据CanalListener

import cn.throwx.canal.gule.CanalGlue;
import com.onecode.dtg.basic.RocketMqConstant;
import lombok.RequiredArgsConstructor;
import org.apache.rocketmq.spring.annotation.RocketMQMessageListener;
import org.apache.rocketmq.spring.core.RocketMQListener;
import org.springframework.stereotype.Component;

/**
 * canal消费数据库操作日志mq
 *
 * @author gideon
 */
@Component
@RequiredArgsConstructor
@RocketMQMessageListener(topic = RocketMqConstant.CANAL_TOPIC, consumerGroup = RocketMqConstant.CANAL_TOPIC)
public class CanalListener implements RocketMQListener<String> {

    private final CanalGlue canalGlue;

    @Override
    public void onMessage(String message) {
        canalGlue.process(message);
    }
}

2. 对我们需要监听的表进行处理ServerCanalListener，这里面的hutool是一个工具类有需要的可以自行引入

<dependency>
    <groupId>cn.hutool</groupId>
    <artifactId>hutool-all</artifactId>
    <version>5.8.6</version>
</dependency>

import cn.hutool.json.JSONUtil;
import cn.throwx.canal.gule.model.CanalBinLogEvent;
import cn.throwx.canal.gule.model.CanalBinLogResult;
import cn.throwx.canal.gule.support.processor.BaseCanalBinlogEventProcessor;
import cn.throwx.canal.gule.support.processor.ExceptionHandler;
import com.onecode.dtg.basic.common.core.exception.CommonBizException;
import com.onecode.dtg.basic.common.enums.ResultCode;
import com.onecode.middle.search.service.bo.ServerBO;
import com.onecode.middle.search.service.constant.EsIndexEnum;
import com.onecode.middle.search.service.util.EsIndexCreateService;
import com.onecode.service.feign.ServerFeignClient;
import com.onecode.service.feign.bo.EsServerBO;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.elasticsearch.action.index.IndexRequest;
import org.elasticsearch.action.index.IndexResponse;
import org.elasticsearch.action.update.UpdateRequest;
import org.elasticsearch.action.update.UpdateResponse;
import org.elasticsearch.client.RequestOptions;
import org.elasticsearch.client.RestHighLevelClient;
import org.elasticsearch.common.xcontent.XContentType;
import org.springframework.stereotype.Component;

import java.io.IOException;

/**
 * @author gideon
 */
@Slf4j
@Component
@RequiredArgsConstructor
public class ServerCanalListener extends BaseCanalBinlogEventProcessor<ServerBO> {

    private final EsIndexCreateService esIndexCreateService;

    private final ServerFeignClient serverFeignClient;

    private final RestHighLevelClient restHighLevelClient;

    /**
     * 插入护理员，此时插入es
     */
    @Override
    protected void processInsertInternal(CanalBinLogResult<ServerBO> result) {
        Long serverId = result.getPrimaryKey();
        EsServerBO esServerBO = serverFeignClient.loadEsServerBO(serverId);
        if (esServerBO == null) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引异常");
        }

//        创建索引
        boolean index = esIndexCreateService.createIndex(EsIndexEnum.SERVER.value(), ServerBO.class, true);
        if (!index) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引：" + EsIndexEnum.SERVER.value() + "失败。");
        }

        IndexRequest request = new IndexRequest(EsIndexEnum.SERVER.value());
        request.id(String.valueOf(serverId));
        request.source(JSONUtil.toJsonStr(esServerBO), XContentType.JSON);
        try {
            IndexResponse indexResponse = restHighLevelClient.index(request, RequestOptions.DEFAULT);
            log.info(indexResponse.toString());

        } catch (IOException e) {
            log.error(e.toString());
            throw new CommonBizException(ResultCode.FAIL.getModel(), "保存es信息异常：" + e);
        }
    }

    /**
     * 更新护理员，删除护理员索引，再重新构建一个
     */
    @Override
    protected void processUpdateInternal(CanalBinLogResult<ServerBO> result) {
        Long spuId = result.getPrimaryKey();
        EsServerBO esServerBO = serverFeignClient.loadEsServerBO(spuId);
        String source = JSONUtil.toJsonStr(esServerBO);

//        创建索引
        boolean index = esIndexCreateService.createIndex(EsIndexEnum.SERVER.value(), ServerBO.class, true);
        if (!index) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引：" + EsIndexEnum.SERVER.value() + "失败。");
        }
        UpdateRequest request = new UpdateRequest(EsIndexEnum.SERVER.value(), String.valueOf(spuId));
        request.doc(source, XContentType.JSON);
        request.docAsUpsert(true);
        try {
            UpdateResponse updateResponse = restHighLevelClient.update(request, RequestOptions.DEFAULT);
            log.info(updateResponse.toString());
        } catch (IOException e) {
            log.error(e.toString());
            throw new CommonBizException(ResultCode.FAIL.getModel(), "删除es信息异常：" + e);
        }
    }

    @Override
    protected ExceptionHandler exceptionHandler() {
        return (CanalBinLogEvent event, Throwable throwable) -> {
            throw new CommonBizException(ResultCode.FAIL.getModel(), "创建索引异常：" + throwable);
        };
    }

}

3. 这个表的监听，是因为我的业务需求，shop_service_server表增加或者删除的时候需要将skuId加到server表的skuId字段里面去，所以需要监听修改。ShopServiceServerCanalListener

import cn.hutool.core.collection.CollUtil;
import cn.hutool.core.util.StrUtil;
import cn.throwx.canal.gule.model.CanalBinLogResult;
import cn.throwx.canal.gule.support.processor.BaseCanalBinlogEventProcessor;
import com.onecode.dtg.basic.common.core.exception.CommonBizException;
import com.onecode.dtg.basic.common.enums.ResultCode;
import com.onecode.middle.search.service.bo.ShopServiceServerBO;
import com.onecode.middle.search.service.manager.ServerUpdateManager;
import com.onecode.service.feign.ServerFeignClient;
import com.onecode.service.feign.bo.EsServerBO;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;

import java.util.List;

/**
 * @author gideon
 */
@Slf4j
@Component
@RequiredArgsConstructor
public class ShopServiceServerCanalListener extends BaseCanalBinlogEventProcessor<ShopServiceServerBO> {

    private final ServerFeignClient serverFeignClient;
    private final ServerUpdateManager serverUpdateManager;

    /**
     * 新增商品服务者数据
     *
     * @param result result
     */
    @Override
    protected void processInsertInternal(CanalBinLogResult<ShopServiceServerBO> result) {
    //数据库操作后的数据
        ShopServiceServerBO afterData = result.getAfterData();
        EsServerBO loadServerBO = loadServerBO(afterData.getServerUserId());
        List<String> skuIdList = StrUtil.split(loadServerBO.getSkuId(), ",");
        skuIdList.add(afterData.getProductSkuId().toString());
        EsServerBO esServerBO = new EsServerBO();
        esServerBO.setSkuId(StrUtil.join(",", skuIdList));
        serverUpdateManager.esUpdateServerByServerId(loadServerBO.getId(), esServerBO);
    }

    /**
     * 更新商品服务者数据
     *
     * @param result result
     */
    @Override
    protected void processUpdateInternal(CanalBinLogResult<ShopServiceServerBO> result) {
    	//数据库执行操作后的数据
        ShopServiceServerBO afterData = result.getAfterData();
        //del字段是我的表是否逻辑删除的判断，大家根据自己需要去掉
        if ("1".equals(afterData.getDel())) {
            return;
        }
        //微服务项目调用接口查询数据
        EsServerBO loadEsServerBO = loadServerBO(afterData.getServerUserId());
        //处理修改后的数据
        EsServerBO esServerBO = dealWithData(afterData, loadEsServerBO);
        serverUpdateManager.esUpdateServerByServerId(loadEsServerBO.getId(), esServerBO);
    }

    /**
     * 删除商品服务者数据
     *
     * @param result result
     */
    @Override
    protected void processDeleteInternal(CanalBinLogResult<ShopServiceServerBO> result) {
    //数据库操作前的数据
        ShopServiceServerBO beforeData = result.getBeforeData();
        EsServerBO loadServerBO = loadServerBO(beforeData.getServerUserId());
        EsServerBO esServerBO = dealWithData(beforeData, loadServerBO);
        serverUpdateManager.esUpdateServerByServerId(loadServerBO.getId(), esServerBO);
    }

    /**
     * 处理数据
     *
     * @param data 数据库操作数据
     * @return EsServerBO
     */
    private EsServerBO dealWithData(ShopServiceServerBO data, EsServerBO loadEsServerBO) {

        List<String> skuIdList = StrUtil.split(loadEsServerBO.getSkuId(), ",");
        CollUtil.removeAny(skuIdList, data.getProductSkuId().toString());
        EsServerBO esServerBO = new EsServerBO();
        esServerBO.setSkuId(StrUtil.join(",", skuIdList));
        return esServerBO;

    }

    /**
     * 获取护理员书信息
     *
     * @param serverUserId 护理员用户标识
     * @return EsServerBO
     */
    private EsServerBO loadServerBO(Long serverUserId) {
        EsServerBO loadEsServerBO = serverFeignClient.loadEsServerBoByServerUserId(serverUserId);
        if (loadEsServerBO == null) {
            throw new CommonBizException(ResultCode.FAIL.getModel(),
                    "es数据同步失败：无法通过护工用户标识：" + serverUserId + "找到护理员信息。");
        }
        return loadEsServerBO;
    }
}

4. ServerUpdateManager，这个是ShopServiceServerListener的处理实现类

import cn.hutool.json.JSONUtil;
import com.onecode.dtg.basic.common.core.exception.CommonBizException;
import com.onecode.dtg.basic.common.enums.ResultCode;
import com.onecode.middle.search.service.constant.EsIndexEnum;
import com.onecode.service.feign.bo.EsServerBO;
import lombok.RequiredArgsConstructor;
import org.elasticsearch.action.bulk.BulkRequest;
import org.elasticsearch.action.bulk.BulkResponse;
import org.elasticsearch.action.update.UpdateRequest;
import org.elasticsearch.client.RequestOptions;
import org.elasticsearch.client.RestHighLevelClient;
import org.elasticsearch.common.xcontent.XContentType;
import org.springframework.stereotype.Component;

/**
 * @author gideon
 */
@Component
@RequiredArgsConstructor
public class ServerUpdateManager {

    private final RestHighLevelClient restHighLevelClient;

    /**
     * 批量更新es中的商品信息
     *
     * @param serverId      护理员标识
     * @param esServerBO 更新的数据
     */
    public void esUpdateServerByServerId(Long serverId, EsServerBO esServerBO) {
        String source = JSONUtil.toJsonStr(esServerBO);
        try {
            BulkRequest request = new BulkRequest();
            // 准备更新的数据
            request.add(new UpdateRequest(EsIndexEnum.SERVER.value(), String.valueOf(serverId)).doc(source, XContentType.JSON));
            //更新
            BulkResponse bulkResponse = restHighLevelClient.bulk(request, RequestOptions.DEFAULT);
            if (bulkResponse.hasFailures()) {
                throw new CommonBizException(ResultCode.FAIL.getModel(), bulkResponse.buildFailureMessage());
            }
        } catch (Exception e) {
            throw new CommonBizException(ResultCode.FAIL.getModel(), e.getMessage());
        }
    }
}

5. ServerSearchManager是搜索接口实现

import cn.hutool.json.JSONUtil;
import com.onecode.dtg.basic.common.core.exception.CommonBizException;
import com.onecode.dtg.basic.common.enums.ResultCode;
import com.onecode.dtg.basic.common.util.ColumnUtil;
import com.onecode.dtg.basic.common.util.LocalDateUtil;
import com.onecode.middle.search.service.bo.ServerBO;
import com.onecode.middle.search.service.constant.EsIndexEnum;
import com.onecode.middle.search.service.dto.ServerSearchDTO;
import com.onecode.middle.search.service.vo.EsPageVO;
import com.onecode.middle.search.service.vo.search.EsServerVO;
import com.onecode.service.feign.constant.AuditStatus;
import com.onecode.service.feign.constant.UseStatus;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.elasticsearch.action.search.SearchRequest;
import org.elasticsearch.action.search.SearchResponse;
import org.elasticsearch.client.RequestOptions;
import org.elasticsearch.client.RestHighLevelClient;
import org.elasticsearch.index.query.BoolQueryBuilder;
import org.elasticsearch.index.query.Operator;
import org.elasticsearch.index.query.QueryBuilders;
import org.elasticsearch.search.SearchHit;
import org.elasticsearch.search.SearchHits;
import org.elasticsearch.search.builder.SearchSourceBuilder;
import org.elasticsearch.search.sort.SortOrder;
import org.springframework.stereotype.Component;

import java.io.IOException;
import java.time.format.DateTimeFormatter;
import java.util.ArrayList;
import java.util.List;
import java.util.Objects;

/**
 * @author gideon
 */
@Slf4j
@Component
@RequiredArgsConstructor
public class ServerSearchManager {

    private final RestHighLevelClient restHighLevelClient;

    /**
     * 通过搜索信息分页搜索es数据的信息
     *
     * @param serverSearchDTO 护理员搜索条件
     * @return 搜索结果
     */
    public EsPageVO<EsServerVO> pageSearchResult(ServerSearchDTO serverSearchDTO) {
        //1、动态构建出查询需要的DSL语句
        EsPageVO<EsServerVO> result;

        //1、准备检索请求
        SearchRequest searchRequest = buildSearchRequest(serverSearchDTO);

        try {
            //2、执行检索请求
            SearchResponse response = restHighLevelClient.search(searchRequest, RequestOptions.DEFAULT);

            log.info("搜索返回结果：" + response.toString());

            //3、分析响应数据，封装成我们需要的格式
            result = buildSearchResult(serverSearchDTO, response);
        } catch (IOException e) {
            log.error(e.toString());
            throw new CommonBizException(ResultCode.FAIL.getModel(), "搜索服务出了点小差，请稍后再试：" + e);
        }
        return result;
    }

    /**
     * 构建结果数据
     */
    private EsPageVO<EsServerVO> buildSearchResult(ServerSearchDTO dto, SearchResponse response) {
        EsPageVO<EsServerVO> esPageVO = new EsPageVO<>();

        //1、返回的所有查询到的商品
        SearchHits hits = response.getHits();
        List<EsServerVO> productSearchs = getEsOrderBOList(response);
        esPageVO.setList(productSearchs);


        //===============分页信息====================//
        //总记录数
        long total = hits.getTotalHits().value;
        esPageVO.setTotal(total);
        // 总页码
        int totalPages = (int) total % dto.getPageSize() == 0 ?
                (int) total / dto.getPageSize() : ((int) total / dto.getPageSize() + 1);
        esPageVO.setPages(totalPages);
        return esPageVO;
    }

    private List<EsServerVO> getEsOrderBOList(SearchResponse response) {

        return getOrderListByResponse(response.getHits().getHits());
    }

    /**
     * 从es返回的数据中获取spu列表
     *
     * @param hits es返回的数据
     * @return
     */
    private List<EsServerVO> getOrderListByResponse(SearchHit[] hits) {
        List<EsServerVO> esOrders = new ArrayList<>();
        for (SearchHit hit : hits) {
            EsServerVO esOrder = JSONUtil.toBean(hit.getSourceAsString(), EsServerVO.class);
            esOrders.add(esOrder);
        }
        return esOrders;
    }


    /**
     * 准备检索请求
     *
     * @param param 搜索参数
     * @return
     */
    private SearchRequest buildSearchRequest(ServerSearchDTO param) {

        SearchSourceBuilder searchSourceBuilder = new SearchSourceBuilder();

        // 构建bool-query
        BoolQueryBuilder boolQueryBuilder = new BoolQueryBuilder();

        // 过滤
        filterQueryIfNecessary(param, boolQueryBuilder);

        // 关键字搜索
        keywordSearch(param, boolQueryBuilder);

        // 排序
        sort(searchSourceBuilder, boolQueryBuilder);

        //分页
        searchSourceBuilder.from((param.getPageNum() - 1) * param.getPageSize());
        searchSourceBuilder.size(param.getPageSize());

        log.info("构建的DSL语句 {}", searchSourceBuilder);

        return new SearchRequest(new String[]{EsIndexEnum.SERVER.value()}, searchSourceBuilder);
    }


    /**
     * 关键字搜索
     */
    private void keywordSearch(ServerSearchDTO param, BoolQueryBuilder boolQueryBuilder) {

        BoolQueryBuilder keywordShouldQuery = QueryBuilders.boolQuery();
//        现住-省
        if (Objects.nonNull(param.getPresentProvince())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getPresentProvince), param.getPresentProvince()).operator(Operator.AND));
        }
//        现住-市
        if (Objects.nonNull(param.getPresentCity())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getPresentCity), param.getPresentCity()).operator(Operator.AND));
        }
//        现住-区
        if (Objects.nonNull(param.getPresentRegion())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getPresentRegion), param.getPresentRegion()).operator(Operator.AND));
        }
//        户籍-省
        if (Objects.nonNull(param.getIdCardProvince())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getIdCardProvince), param.getIdCardProvince()).operator(Operator.AND));
        }
//        户籍-市
        if (Objects.nonNull(param.getIdCardCity())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getIdCardCity), param.getIdCardCity()).operator(Operator.AND));
        }
//        户籍-区
        if (Objects.nonNull(param.getIdCardRegion())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getIdCardRegion), param.getIdCardRegion()).operator(Operator.AND));
        }

//        标签
        if (Objects.nonNull(param.getIntroLabels())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getIntroLabel), param.getIntroLabels()).operator(Operator.AND));
        }
//        排班，使用了我的自定义逗号分词器，所以是根据逗号分隔后进行匹配的，但是需要多个匹配，我就使用了for循环，应该是有优化的地方，暂时没处理
        if (param.getServiceStartDate() != null && param.getServiceEndDate() != null) {
            List<String> scheduleList = LocalDateUtil.getContinuousTime(param.getServiceStartDate(), param.getServiceEndDate(), DateTimeFormatter.ofPattern("yyyyMMdd"));
            for (String schedule : scheduleList) {
                keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getSchedule), schedule).operator(Operator.AND));
            }
        }
//        skuId，使用了我的自定义逗号分词器，所以是根据逗号分隔后进行匹配的
        if (Objects.nonNull(param.getSkuId())) {
            keywordShouldQuery.should(QueryBuilders.matchQuery(ColumnUtil.getName(ServerBO::getSkuId), param.getSkuId()).operator(Operator.AND));
        }
        boolQueryBuilder.must(keywordShouldQuery);
    }

    /**
     * 进行排序
     */
    private void sort(SearchSourceBuilder searchSourceBuilder, BoolQueryBuilder boolQueryBuilder) {
        searchSourceBuilder.sort(ColumnUtil.getName(ServerBO::getCreateTime), SortOrder.DESC);
        searchSourceBuilder.query(boolQueryBuilder);
    }

    /**
     * 过滤查询条件，如果有必要的话
     *
     * @param param            查询条件
     * @param boolQueryBuilder 组合进boolQueryBuilder
     */
    private void filterQueryIfNecessary(ServerSearchDTO param, BoolQueryBuilder boolQueryBuilder) {
//        类型
        if (Objects.nonNull(param.getType())) {
            boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getType), param.getType()));
        }
//        性别
        if (Objects.nonNull(param.getGender())) {
            boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getGender), param.getGender()));
        }
//        学历
        if (Objects.nonNull(param.getEducation())) {
            boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getEducation), param.getEducation()));
        }
        boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getAuditStatus), AuditStatus.PASS.getStatus()));
        boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getUseStatus), UseStatus.NORMAL.getStatus()));
        boolQueryBuilder.filter(QueryBuilders.termQuery(ColumnUtil.getName(ServerBO::getDel), 0));
    }
}

6. ServerSearchController

import com.onecode.dtg.basic.common.model.ResultBean;
import com.onecode.middle.search.service.dto.ServerSearchDTO;
import com.onecode.middle.search.service.manager.ServerSearchManager;
import com.onecode.middle.search.service.vo.EsPageVO;
import com.onecode.middle.search.service.vo.search.EsServerVO;
import io.swagger.annotations.Api;
import lombok.AllArgsConstructor;
import org.springframework.validation.annotation.Validated;
import org.springframework.web.bind.annotation.*;

/**
 * @author gideon
 * @date 2022/9/6
 */
@Validated
@AllArgsConstructor
@RestController
@RequestMapping("/search/server/")
@Api(tags = "api-服务者搜索接口")
public class ServerSearchController {

    private final ServerSearchManager serverSearchManager;

    @PostMapping("/page")
    public ResultBean<EsPageVO<EsServerVO>> page(@RequestBody ServerSearchDTO dto) {
        return new ResultBean<>(serverSearchManager.pageSearchResult(dto));
    }

}

7. 分页参数EsPageDTO实体类

import com.onecode.dtg.basic.common.util.PrincipalUtil;
import io.swagger.annotations.ApiModelProperty;
import lombok.Data;

import javax.validation.constraints.NotNull;
import java.util.Arrays;

/**
 * @author gideon
 */
@Data
public class EsPageDTO {

    public static final String ASC = "ASC";

    public static final String DESC = "DESC";

    /**
     * 最大分页大小，如果分页大小大于500，则用500作为分页的大小。防止有人直接传入一个较大的数，导致服务器内存溢出宕机
     */
    public static final Integer MAX_PAGE_SIZE = 500;

    /**
     * 当前页
     */
    @NotNull(message = "pageNum 不能为空")
    @ApiModelProperty(value = "当前页", required = true)
    private Integer pageNum;

    @NotNull(message = "pageSize 不能为空")
    @ApiModelProperty(value = "每页大小", required = true)
    private Integer pageSize;

    @ApiModelProperty(value = "排序字段数组，用逗号分割")
    private String[] columns;

    @ApiModelProperty(value = "排序字段方式，用逗号分割，ASC正序，DESC倒序")
    private String[] orders;

    public Integer getPageNum() {
        return pageNum;
    }

    public void setPageNum(Integer pageNum) {
        this.pageNum = pageNum;
    }

    public Integer getPageSize() {
        return pageSize;
    }

    public void setPageSize(Integer pageSize) {
        if (pageSize > MAX_PAGE_SIZE) {
            this.pageSize = MAX_PAGE_SIZE;
            return;
        }
        this.pageSize = pageSize;
    }

    public String getOrderBy() {
        return order(this.columns, this.orders);
    }

    public String[] getColumns() {
        return columns;
    }

    public void setColumns(String[] columns) {
        this.columns = columns;
    }

    public String[] getOrders() {
        return orders;
    }

    public void setOrders(String[] orders) {
        this.orders = orders;
    }

    public static String order(String[] columns, String[] orders) {

        if (columns == null || columns.length == 0) {
            return "";
        }

        StringBuilder stringBuilder = new StringBuilder();

        for (int x = 0; x < columns.length; x++) {

            String column = columns[x];
            String order;

            if (orders != null && orders.length > x) {
                order = orders[x].toUpperCase();
                if (!(order.equals(ASC) || order.equals(DESC))) {
                    throw new IllegalArgumentException("非法的排序策略：" + column);
                }
            } else {
                order = ASC;
            }

            // 判断列名称的合法性，防止SQL注入。只能是【字母，数字，下划线】
            if (PrincipalUtil.isField(column)) {
                throw new IllegalArgumentException("非法的排序字段名称：" + column);
            }

            // 驼峰转换为下划线
            column = humpConversionUnderscore(column);

            if (x != 0) {
                stringBuilder.append(", ");
            }
            stringBuilder.append("`").append(column).append("` ").append(order);
        }
        return stringBuilder.toString();
    }

    public static String humpConversionUnderscore(String value) {
        StringBuilder stringBuilder = new StringBuilder();
        char[] chars = value.toCharArray();
        for (char character : chars) {
            if (Character.isUpperCase(character)) {
                stringBuilder.append("_");
                character = Character.toLowerCase(character);
            }
            stringBuilder.append(character);
        }
        return stringBuilder.toString();
    }


    @Override
    public String toString() {
        return "EsPageDTO{" +
                "pageNum=" + pageNum +
                ", pageSize=" + pageSize +
                ", columns=" + Arrays.toString(columns) +
                ", orders=" + Arrays.toString(orders) +
                '}';
    }
}

8. 查询参数实体类ServerSearchDTO

import io.swagger.annotations.ApiModelProperty;
import lombok.Data;
import lombok.EqualsAndHashCode;

import javax.validation.constraints.NotNull;
import java.time.LocalDate;

/**
 * @author gideon
 */
@EqualsAndHashCode(callSuper = true)
@Data
public class ServerSearchDTO extends EsPageDTO{

    @ApiModelProperty("类型")
    private String type;

    @ApiModelProperty("值为1时是男性，值为2时是女性，值为0时是未知")
    private String gender;

    @ApiModelProperty("学历")
    private String education;

    @ApiModelProperty("户籍-省")
    private String idCardProvince;

    @ApiModelProperty("户籍-市")
    private String idCardCity;

    @ApiModelProperty("户籍-区")
    private String idCardRegion;

    @ApiModelProperty("现住-省")
    private String presentProvince;

    @ApiModelProperty("现住-市")
    private String presentCity;

    @ApiModelProperty("现住-区")
    private String presentRegion;

    @ApiModelProperty("介绍-标签（多个值需要使用逗号分割）")
    private String introLabels;

    @ApiModelProperty("服务开始时间")
    @NotNull(message = "服务开始时间不能为空")
    private LocalDate serviceStartDate;

    @ApiModelProperty("服务结束时间")
    @NotNull(message = "服务结束时间不能为空")
    private LocalDate serviceEndDate;

    @ApiModelProperty("skuId")
    @NotNull(message = "skuId不能为空。")
    private Long skuId;

}

9. 返回值EsServerVO参数

/**
 * @author gideon
 * @date 2022/9/5
 */
@Data
public class EsServerVO {

    @ApiModelProperty("id")
    private Long id;

    @ApiModelProperty("用户标识")
    private Long userId;

    @ApiModelProperty("类型")
    private String type;

    @ApiModelProperty("姓名")
    private String name;

    @ApiModelProperty("值为1时是男性，值为2时是女性，值为0时是未知")
    private String gender;

    @ApiModelProperty("出生年月日")
    @JsonFormat(pattern = "yyyy-MM-dd")
    private LocalDate birthday;

    @ApiModelProperty("学历")
    private String education;

    @ApiModelProperty("从业时间")
    @JsonFormat(pattern = "yyyy-MM-dd")
    private LocalDate practiceDate;

    @ApiModelProperty("评级")
    private String level;

    @ApiModelProperty("认证标签")
    private String authLabel;

    @ApiModelProperty("勋章（逗号隔开）")
    private String medal;

    @ApiModelProperty("服务评分")
    private Integer serviceScore;

    @ApiModelProperty("已实名认证")
    private Integer realNameAuth;

    @ApiModelProperty("身份证号")
    private String idCardNo;

    @ApiModelProperty("户籍-省")
    private String idCardProvince;

    @ApiModelProperty("户籍-市")
    private String idCardCity;

    @ApiModelProperty("户籍-区")
    private String idCardRegion;

    @ApiModelProperty("手机号")
    private String phone;

    @ApiModelProperty("现住-省")
    private String presentProvince;

    @ApiModelProperty("现住-市")
    private String presentCity;

    @ApiModelProperty("现住-区")
    private String presentRegion;

    @ApiModelProperty("现住-地址")
    private String presentAddress;

    @ApiModelProperty("头像")
    private String head;

    @ApiModelProperty("使用状态（初始化：init;正常：normal，禁用：ban）")
    private String useStatus;

    @ApiModelProperty("审核状态 （待审核：await;通过：pass，驳回：reject）")
    private String auditStatus;

    @ApiModelProperty("驳回理由")
    private String rejectReason;

    @ApiModelProperty("注册时间")
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    private LocalDateTime regDate;

    @ApiModelProperty("介绍-内容")
    private String introContent;

    @ApiModelProperty("介绍-视频")
    private String introVideo;

    @ApiModelProperty("介绍-标签")
    private String introLabel;

    @ApiModelProperty("商家标识")
    private Long merchantId;

    @ApiModelProperty("组织标识")
    private Long orgId;

    @ApiModelProperty("护理员申请sku,多个逗号隔开")
    private String skuId;

    @ApiModelProperty("护理员排班数据，多个逗号隔开")
    private String schedule;

    /**
     * 逻辑删除
     */
    private Integer del;

    /**
     * 创建人
     */
    private String createBy;

    /**
     * 创建时间
     */
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    private LocalDateTime createTime;

    /**
     * 更新者
     */
    private String updateBy;

    /**
     * 更新时间
     */
    @JsonFormat(pattern = "yyyy-MM-dd HH:mm:ss")
    private LocalDateTime updateTime;
}

10. 分页返回值EsPageVO

import io.swagger.annotations.ApiModelProperty;
import lombok.Data;

import java.util.List;

/**
 * @author gideon
 * @date 2022/9/5
 */
@Data
public class EsPageVO<T> {

    @ApiModelProperty("总页数")
    private Integer pages;

    @ApiModelProperty("总条目数")
    private Long total;

    @ApiModelProperty("结果集")
    private List<T> list;
}
